EZ Koat 15 Plus

UV/Aqueous Coating & Curing System for cut-sheets

The Kompac EZ Koat 15 Plus is a cost effective, entry level flood coating and priming system. Capable of coating a sheet size of 14.5” wide by virtually any length, users can easily apply UV, aqueous, specialty coatings and primers. Whether digital output or offset, each job will have the visual appeal, lasting durability, protection and rub resistant finish that your customers expect! The EZ Koat 15 Plus produces the highest gloss and a perfect finish every time!

  • Compact and can be used offline
  • Easily apply UV, aqueous, specialty coatings and primers
  • Provides coating control and speed adjustment on-the-fly with the color touch screen
  • Uses Solid State Digital UV lamp controller that permits infinite curing and temperature control, saving power and money
  • Eliminates the need for re-circulation of the coating – no waste!
  • 2-minute coating change (no tanks to clean!)
  • Made in the USA

Cost Effective, Entry-Level Flood Coating and Priming System

Enhance the look and value of product brochures, catalog covers, postcards, business cards, flyers, and more using the EZ Koat 15 Plus. This offline coating/curing system provides a quick and easy way to apply UV, aqueous, primer & specialty coatings to a wide variety of substrates including those that are digitally printed.

The Kompac EZ Koat 15 is a small footprint coating system capable of applying UV and Aqueous coatings and primers to substrates.

Product Specifications

Sheet Size: 14.5" (368mm) width, virtually any length (hand-fed)
UV Lamp: Solid State - infinitely variable UV Solid State
Speed:  Up to 100 feet (30.5 meters) per minute
Stock Weight:  7pt. to 30pt. 150g/m² to 600g/m²
Controls: Adjustable speed & UV intensity
Weight:  400lbs. 181kgs.
Dimensions:  78" L x 29"W x 50"H 1.98m x .74m x 1.27m
Electrical:  208-230/1Φ/50-60Hz/25 amps



Want More Information?

Name *
Name


Available Options

Coating sensor: Automatically detects coating level & replenishes as needed
6kW Lamp Driver: Enables up to 400W/inch for difficult curing applications (3kW standard, 200W/inch)
Exhaust/Vacuum System: Provides vacuum for additional sheet control, fume and heat ventilation, and cooling for 6kW option.
Coating Agitator: Allows running UV matte and soft touch coatings.
Cool UV: Add on for heat sensitive substrates.



Kompac Coatings & Primers

A proper coating can enhance the appearance and durability, increasing the printed product’s value. Kompac offers a wide range of finishing options, with a complete line of UV, aqueous, specialty coatings and primers available for all products. Kompac will help you create a visually outstanding finished product! Place orders through our website, or by contacting our sales department. Available in 1, 2.5 & 5 gallon pails, these coatings can be ordered and shipped worldwide.

In addition to regular coatings, Kompac has developed custom coating solutions for special applications, and aqueous and UV primers for difficult to print on substrates. These special purpose coatings can be used for the following applications:

•Soft touch•Writing/gluing •Dry erase •Silver/gold scratch off •Blister packaging
•Non-skid/sand •Food grade application•Playing cards •White opaque
